A few nice turning China machining images I found:
Turning 205 horses into 1,300
Image by SkipSteuart
AR Fabrication can give your car balls.
6-shot HDR
stock B18C Integra Engine: 205 BHP
AR20R upgrade: 1300 BHP
World record quarter mile: 7.9 sec at 189 MPH
2200 lbs curb weight
Custom Jig – Expanding arbor into a C5 collet
Image by nebarnix
For accessing all of the surfaces with the lathe and keeping the mating surfaces pristine. 3 degree expanding taper turned to force workpiece back and firmly against onto registration surface when tightened.
Custom Jig – Expanding arbor into a C5 collet
Image by nebarnix
For accessing all of the surfaces with the lathe and keeping the mating surfaces pristine. 3 degree expanding taper turned to force workpiece back and firmly against onto registration surface when tightened.
